STW75N65DM6-4: This high-voltage N-channel Power MOSFET offers one of the most effective switching behaviors available on the market for the most demanding high-efficiency bridge topologies and ZVS phase-shift converters
Compared with the previous generation of MDmesh fast-recovery diode series, the DM6 series combines very low recovery charge (Qrr), recovery time (trr) and a greatly improved RDS(on) per area with one of the most effective switching behaviors available on the market for the most demanding high-efficiency bridge topologies and ZVS phase-shift converters.
Key features of STW75N65DM6-4
- Fast-recovery body diode
- Lower RDS(on) per area vs previous generation
- Low gate charge, input capacitance and resistance
- 100% avalanche tested
- Extremely high dv/dt ruggedness
- Zener-protected
- Excellent switching performance thanks to the extra driving source pin
Application examples
Switching applications Recommended resources
