Product overview
Description
The AEK-POW-100W4V1 is a very compact DC-DC converter for automotive and transportation applications which allows regulating the output voltage in the following modes: fixed outputs and Programmable Power Supply (PPS) in 20 mV steps.
The board allows setting the output current from a min. of 0.05 A to a max. of 5 A for the entire output voltage range in 50 mA steps.
It features several protection systems, such as short-circuit, overcurrent and thermal protection.
The AutoDevKit software library includes dedicated components able to configure and drive the board via ST microcontrollers.
-
All features
- Up to 100 W power on a single DC-DC channel
- Input voltage range: 6 V to 26 V
- MCU selectable fixed outputs: 3.3 V, 5 V, 9 V, 15 V, 20 V
- Programmable max. output current up to 5 A in steps of 50 mA
- Programmable output voltages: 20 mV steps from 3.3 to 11 V
- Short-circuit, overcurrent and thermal protections
- Size: 84.7 mm x 81.3 mm
- Included in the AutoDevKit initiative
- RoHS compliant
