製品概要
概要
The SATEL-VL53L4CD package includes two breakout boards, which can be easily integrated into the customer's devices.
The PCB section that embeds the VL53L4CD module is perforated. The developers can then break off the mini-PCB and use it in a 3.3 V supply application via flying wires.
This makes it easier to integrate the SATEL-VL53L4CD breakout boards into the development and evaluation devices thanks to their small size.
-
特徴
- VL53L4CD Time-of-Flight high-accuracy proximity sensor
- High-performance proximity ranging, independent of the target size and reflectance
- From 0 to 1300 mm with full field of view (FoW)
- Short distance linearity down to 1 mm
- Divisible board that can be used as a mini-PCB breakout board, easy to integrate into the customer's device
- Two breakout boards available in the package
- Compatible with X-NUCLEO-53L4A1
おすすめ製品
X-NUCLEO-53L4A1
Time-of-Flight high-accuracy proximity sensor expansion board based on the VL53L4CD for STM32 Nucleo
P-NUCLEO-53L4A1
VL53L4CD STM32 Nucleo pack with X-NUCLEO-53L4A1 expansion board and NUCLEO-F401RE development board
X-CUBE-TOF1
Time-of-Flight sensors software expansion for STM32Cube
推奨コンテンツ
関連アプリケーション
ファンクション
All tools & software
-
-
