Products & Key Features for Motor Control
The STM32 portfolio includes devices based on Arm® Cortex®-M cores (M0, M0+, M3, M33, M4, and M7). Thanks to the MCUs' shared ecosystem, developers benefit from enhanced flexibility to move forward with their motor control design. STM8 MCUs, our 8-bit family of microcontrollers, complement our offer and enable the design of very cost-sensitive motor control solutions.
Each STM32 series offers a different set of peripherals matching different Motor Control application requirements.
STM32 F3 series and G4 series
The STM32G4 series combines a 32-bit Arm® Cortex®-M4 core (with FPU and DSP instructions) running at 170 MHz combined with three different hardware accelerators, rich analog peripherals and advanced motor control timers to meet all motor control application requirements. These product series are ideal for Motor Control applications.
STSPIN32F0
The STSPIN32F0 is a System-In-Package providing an integrated solution suitable for driving three-phase BLDC motors using different driving modes. This product series combines an STM32F031 microcontroller with triple half-bridge gate driver able to drive power MOSFETs or IGBTs with a current capability of 600 mA (sink and source) as well as other analog components.
STSPIN32G0
The STSPIN32G0 series is an integrated motor control solution for driving three-phase brushless motors using different driving modes. These Systems-in-Package series combines an advanced 3-Phase Gate Drivers able to drive power MOSFETs or IGBTs with an STM32G031 microcontroller embedding 64Kb Flash and 8Kb SRAM. The integrated power management and analog components make STSPIN32G0 a convenient and efficient choice for motor control designs.
STSPIN32G4
The STSPIN32G4 is a System-In-Package enabling your high-end three-phase brushless motor driving applications with extra computational capacity and a high-performance gate driver. This product series combines an STM32G431 microcontroller, a triple half-bridge gate driver with advanced features, and power management in a small 9x9 mm QFN package.
