STEVAL-ISB019V1

NRND
MySTに保存する

Evaluation board for STCC2540 USB charging controller

データブリーフのダウンロード
概要

製品概要

概要

This STEVAL-ISB019V1 evaluation board allows the easy measurement of STCC2540 parameters and the evaluation of all its functions and operating modes.

  • 特徴

    • USB 2.0 SDP or CDP data pass-through with S3 remote wakeup support or automatic charging
    • Permanent USB 3.0 SuperSpeed data pass-through between input and output USB connector
    • CDP mode with charging indication after CDP negotiation
    • DCP modes with charging indication (BC1.2 mode, divider mode, auto-detect mode)
    • Charging/end-of-charging detection and indication
    • Resistor-programmable precise current limiter and short-circuit protection
    • RoHS compliant
